Jupiter® Model JM4

Jupiter® JM4 magnetostrictive level transmitter

The Jupiter^® JM4 liquid level transmitter is a loop-powered 24 VDC liquid-level transmitter and is available as a direct insertion transmitter or as an external mounted transmitter onto a Magnetic Level Indicator. It relies on the position of a magnetic float which is designed precisely for the liquid to be measured. This high-accuracy device can be designed for liquid level and/or liquid-liquid interface measurement.

The high safety level of JUPITER is demonstrated by a Safe Failure Fraction > 90 %

Technology

Magnetostrictive

A low-energy pulse, generated by the JUPITER electronics, travels the length of the magnetostrictive wire. A return signal is generated from the precise location where the magnetic field of a float intersects the wire. A timer precisely measures the elapsed time between the generation of the pulse and the return of the acoustic signal. Each cycle occurs ten times per second, providing real-time and highly accurate level data.

Features

• 4-button user interface and graphical LCD display provide enhanced depth of data, indicating on-screen waveforms and troubleshooting tips.
• 4-20 mA output
• Rotatable housing can be dismantled without depressurising the vessel via “Quick connect/disconnect” probe coupling.
• Ergonomic dual compartment enclosure
• Simple set-up and configuration
• Smart Probe Technology
• Easy attachment to an MLI
• Direct insertion for a wide variety of vessels and applications

Options

• HART^® or FOUNDATION Fieldbus digital communications
• Hastelloy^® or Monel^® materials of construction
• Threaded or flanged process connections
• External Jupiter models can be top or bottom mounted to an MLI
• SIL certificate
